TLM-09 Off Road Go Kart Kits 48V 500W Motor Electric Family Go Karts
Explore the outdoors with the TLM-09 Off Road Go Kart Kits. This 48V 500W family go kart is built for hardened roads, flat surfaces, and slopes under 15°. With speeds up to 35KM/H, tubeless tires, and hydraulic disc brakes, it’s perfect for family rides. Customizable to meet your specific requirements.
Product Parameters
| Item | Specification |
| Motor | 48V 500W motor |
| Overall Size | 1800 × 1150 × 1230 mm |
| Package Size | 1830 × 1180 × 670 mm |
| Max Load | 100kg |
| Net Weight | 100kg |
| Recommended Age | 13+ years old |
| Max Speed | 35KM/H |
| Range | 35~40KM |
| Ground Clearance | 110MM |
| Traversable Terrain | Hardened road, flat road surface, slopes below 15° |
| Operating Temperature | 14°F~104°F (-10～40℃) |
| Battery Voltage | 48V |
| Battery Capacity | 20Ah |
| Charging Time | 6 hours |
| Battery Type | 8V 20Ah lead-acid battery (upgradable to 48V 35Ah lithium-ion battery) |
| Tires | Front tires: 6-in tubeless tires; Rear tires: 7-in tubeless tires. Front wheels: AT145/70-6; Rear wheels: 16×8.00-7 in |
| Brake System | Hydraulic disc brake |
| Turning Radius | 6M |
| Warranty | Frame, motor, controller: 1-year; Battery: 3-month replacement, repair thereafter |
| Color Options | Orange and red available; customizable |
| Seat Adjustment | 16 cm adjustable rail |
| Safety Belt | Two-point seatbelt |
